Specifications
Type: Normally open
Pipe size: Flange connection DN40
Orifice: 40 mm
Body material: SS304
Seal meterial: VITON
Operating pressure: 0-5 bar
Temperature: <120ºC
Fluid media: water, gas, air, light oil <20 CST
Voltage: 220VAC (can be optional 110VAC/24VAC/24VDC/12VDC)
Warranty: 2 years
